Package Contents
7. Luminaire Module
F4IN-120V-R1-30
8. Luminaire Cover
RPL-F1801-COVER-**
9. Acrylic Shade
RPL-F1801-GLA
10. Receiver w/Hardware (***)
F-R3-1801-0**
11. Remote w/Wall Cradle
F-RCBT-WT
Hardware Bag
RPL-F1801-**-PARTS
1. Blade Set of 5
(42” / 52” / 60”)
RPL-F1801-**-BD-**
2. Mounting Bracket
Downrod Assembly
RPL-HGR-ASM-**
3. Coupling Cover
RPL-COU-CVR-**
4. Canopy & Canopy Ring
RPL-CAN-CYL-**
5. Motor Housing
6. Adapter Plate
** denotes finish code of fan
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
A
Outlet Box Machine Screws (2)
Spring Washers (2)
Flat Washers (2)
B
Blades Screw with Fiber Washers (16)
C
Electrical
Connections
Wire Nuts (8)
D
Safety Cable Wood Screw (1)
Spring Washer (1)
Flat Washer (1)
