Modine Manufacturing BAE - Dimensional Data

15
DIMENSIONAL DATA
Dimensions (in inches)
A
C
B
/4"
3
D
B
A
/4"
3
C
D
B
C
D
A
/4"
3
40°
Downward Nozzles
90°
Downward Nozzles
B
A
/4"
3
C
D
40°
Splitter Nozzles
5-Way
Nozzle
A 14-13/16 16-13/16 18-9/16 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 26-3/16 31-1/8 31-1/8 37-1/2
B 16 16 20 20 20 24 24 24 24 24 24 24
C 24 22 26 26 25 30 30 30 30 36 36 36
D 4 3 4 4 4 4 4 6 6 11 11 11
A 14-13/16 16-13/16 18-9/16 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 26-3/16 31-1/8 31-1/8 37-1/2
B 16 16 20 20 20 24 24 24 24 24 24 24
C 15 17 22 22 23 29 29 30 30 34 34 34
D 6 6 8 8 8 10 10 10 10 14 14 14
A – – 18-9/16 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 26-3/16 31-1/8 31-1/8 37-1/2
B – – 20 20 20 24 24 24 24 24 24 24
C – – 34 34 33 39 39 40 40 46 46 47
D – – 10 10 11 12 12 14 14 19 19 20
A 14-13/16 16-13/16 18-9/16 18-9/16 21 23-3/16 23-3/16 26-3/16 26-3/16 31-1/8 31-1/8 37-1/2
B 16 16 20 20 20 24 24 24 24 24 24 24
C 20-3/4 22-3/4 24-1/2 24-1/2 27 29 29 32 32 37 37 43-1/2
D 11 12 13 13 14 15 15 16 16 18 18 18
M
odel Number
40° Downward
Nozzle
90° Vertical
Nozzle
40° Splitter
Nozzle
5-Way
Nozzle
Nozzle
Type
Dimension
Symbol
BAE-50 BAE-75 BAE-100 BAE-125 BAE-145 BAE-175 BAE-200 BAE-225 BAE-250 BAE-300 BAE-350 BAE-400
