PD 50 PD 75 PD 100 PD 125 PD 150 PD 175 PD 200 PD 250 PD 300 PD 350 PD 400
Models
S S S S S S S S S S S
8'
10 23 30 34 38 42 36 54 62 58 56
10'
11 20 27 30 34 37 32 48 56 52 50
12'
12 19 24 27 31 34 29 44 51 47 46
14'
17 23 25 29 32 27 41 47 44 42
16'
16 21 24 27 29 25 38 44 41 39
18'
20 22 25 28 24 36 42 38 37
20'
19 21 24 26 23 34 40 36 35
22'
23 25 22 33 38 35 34
24'
31 36 33 32
26'
30 35 32 31
28'
29 33 31 30
3
0'
32 30 29
PD 50 PD 75 PD 100 PD 125 PD 150 PD 175 PD 200 PD 250 PD 300 PD 350 PD 400
Models
X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z
8'
0 19 26 0 26 36 0 33 45 0 34 47 0 38 52 0 40 55 0 35 47 0 47 65 0 52 72 0 49 68 0 48 66
10'
0 14 19 0 23 32 0 31 42 0 32 44 0 36 49 0 39 53 0 33 45 0 46 63 0 51 70 0 48 66 0 47 64
12'
0 18 25 0 28 38 0 29 40 0 33 46 0 36 50 0 30 41 0 44 60 0 50 68 0 46 64 0 45 62
14'
0 10 14 0 23 33 0 25 35 0 30 41 0 33 46 0 26 36 0 41 57 0 48 65 0 44 61 0 43 59
16'
0 13 19 0 18 25 0 25 35 0 29 41 0 19 27 0 38 53 0 45 62 0 41 57 0 40 55
18'
0 12 17 0 13 19 0 23 32 0 12 17 0 35 48 0 42 58 0 38 52 0 36 50
20'
0 29 40 0 38 52 0 33 46 0 31 43
22'
0 16 23 0 32 45 0 25 35 0 21 30
2
4'
0 19 28 0 16 24 0 16 23
PD 50 PD 75 PD 100 PD 125 PD 150 PD 175 PD 200 PD 250 PD 300 PD 350 PD 400
Models
X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z X Y Z
8'
8 19 26 11 25 34 14 31 43 15 32 44 16 36 49 18 38 52 15 33 45 21 44 60 24 49 67 22 46 63 22 45 62
10
' 6 15 22 9 23 22 13 30 41 14 31 43 15 34 47 17 37 51 14 31 43 20 43 59 23 48 66 21 45 62 21 44 61
12'
4 12 17 7 20 28 11 28 39 12 29 40 14 33 45 15 35 49 12 30 41 19 42 58 21 47 65 20 44 61 19 43 59
14'
5 14 21 10 25 35 10 26 37 12 30 42 14 33 46 11 27 37 17 40 56 20 46 63 19 43 59 18 42 57
16'
5 17 25 7 21 30 10 27 38 12 31 43 8 22 31 16 38 53 19 44 61 17 41 56 16 40 55
18'
6 18 26 6 20 29 9 26 37 6 18 26 14 36 50 17 42 58 15 38 53 15 37 52
20'
12 32 45 15 39 54 13 35 49 13 33 47
22'
8 24 35 13 35 49 10 29 42 8 25 37
2
4'
8 26 38 8 24 36 8 24 35
Mounting
Height to
Bottom of
Heater
Mounting
Height to
Bottom of
Heater
16
PERFORMANCE DATA – HOODS FOR PROPELLER MODELS
Performance Data — 30°, 60° and 90° Downward Deflector Hoods
OUNTING
HEIGHT
X
Y
Y
Z
Z
X
60 NOZZLE
30 NOZZLE
60
30
30 DOWNTURN NOZZLE
60 DOWNTURN NOZZLE
NOTE:
X = FEED FROM HEATER
TO START OF
FLOOR COVERAGE.
Y = FEET TO END OF
FLOOR COVERAGE.
Z = FEET TO END OF
THROW.
30° HOOD 60° HOOD
THROW-FLOOR COVERAGE
M
ounting
Height to
Bottom of
Heater
30° Downward Hood For Propeller Units
➀
➀
Data Based on units fired at full rated input with an entering air temperature of 60°-80°F. Maximum mounting heights higher versus units without outlet devices.
60° Downward Hood For Propeller Units
➀
90° Downward Hood For Propeller Units
➀
