Modine Manufacturing BD - Dimensional Data

15
DIMENSIONAL DATA
Dimensions (in inches)
A
C
B
/
4"
D
B
A
/4"
3
C
D
B
C
D
A
/4"
3
40°
Downward Nozzles
90°
Downward Nozzles
B
A
/4"
3
C
D
40°
Splitter Nozzles
5-Way
Nozzle
A 14-13/16 14-13/16 16-13/16 16-13/16 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 31-1/8 37-1/2
B 13 16 16 20 20 20 24 24 24 24 24
C 20 24 22 26 26 25 30 30 30 36 36
D 3-1/2 4 3 4 4 4 4 4 6 11 11
A 14-13/16 14-13/16 16-13/16 16-13/16 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 31-1/8 37-1/2
B 13 16 16 20 20 20 24 24 24 24 24
C 15 15 17 22 22 23 29 29 30 34 34
D 6 6 6 8 8 8 10 10 10 14 14
A – – – – 18-9/16 21-1/16 23-3/16 23-3/16 26-3/16 31-1/8 37-1/2
B – – – – 20 20 24 24 24 24 24
C – – – – 34 33 39 39 40 46 47
D – – – – 10 11 12 12 14 19 20
A 14-13/16 14-13/16 16-13/16 16-13/16 18-9/16 21 23-3/16 23-3/16 26-3/16 31-1/8 37-1/2
B 13 16 16 20 20 20 24 24 24 24 24
C 20-3/4 20-3/4 22-3/4 22-3/4 24-1/2 27 29 29 32 37 43-1/2
D 11 11 12 12 13 14 15 15 16 18 18
Model Number
40° Downward
Nozzle
90° Vertical
Nozzle
40° Splitter
Nozzle
5-Way
Nozzle
Nozzle
Type
Dimension
Symbol
BD 50 BD 75 BD 100 BD 125 BD 150 BD 175 BD 200 BD 250 BD 300 BD 350 BD400
