MODEL NOMENCLATURE
Figure 32.1 - Model Number Designations
PDP 200 A E 01 30 S B A N
Unit Conguration
HD - Tubular Power Vented Propeller Unit
HDB - Tubular Power Vented Blower Unit
PDP - Propeller Unit Power Vent
BDP - Blower Unit Power Vent
PTP - Tubular Power Vented Propeller Unit
Control Code Type
(refer to page 14)
11 - Natural gas, single stage (HD/HDB)
21 - Propane, single stage (HD/HDB)
30 - 115v/25v intermittent pilot ignition, 100% Shut-Off,
with continuous retry, natural gas
31 - 230v/25v intermittent pilot ignition, 100% Shut-Off,
with continuous retry, natural gas
etc.
Fan Guard Digit
S - Standard
F - Fingerproof
N - None (all blower models)
Future
A - All
Factory Installed Option Digit
N - None
Dev Digit
MBH Input
(refer to pages 7 & 9)
100 - 100,000 Btu/hr input
200 - 200,000 Btu/hr input
250 - 250,000 Btu/hr input
etc.
Heat Exchanger Type
A - Aluminized
S - Stainless Steel
Ignition Type
E - Unit equipped with intermittent pilot ignition
S - Direct Spark (HD/HDB/PTP only)
Power Code
(refer to pages 10 & 11)
01 - 115V/60Hz/1ph
02 - 230V/60Hz/1ph
etc.
