Moduline CSC 031E - General Recommendations and Technical Data

GENERAL RECOMMENDATIONS
AND TECHNICAL DATA
GB
Ed. 0117
17
Example of rating plate
TECHNICAL DATA
Model (type)
Rated voltage
[Vac]
Total input
[kW]
Amps.
[A]
Cable according to IEC
-
60245
-
57 (H05RN
-
F
or HO7RN-F). Minimum cross section of
connection cable [mm2]
CSC031E (CSC031E)
230 50Hz
220-240
50 / 60Hz
0,7 3,1
3 x 1
CSC051E (CSC051E)
1 4,4
CSC052E (CSC052E)
1,5 6,6
CSD011E (CSD011E)
0,7 3,1
CSD012E (CSD012E)
1 4,4
CSD013E (CSD013E)
CSD001E (CSD001E)
1,5 6,6
CSD002E (CSD002E)
0,7 3,1
CSD003E (CSD003E)
1 4,4
Model (type)
Operating
temperature (°C)
Tray capacity:
distance [mm]
Tray max. height [mm]
Maximum total load
(product + trays) (kg)
Weight when empty
(Kg)
CSC031E
(CSC031E)
30 ÷ 120
3 x GN 1/1 (70)
3 x 65 (h) 1 x 200 (h)
11 + 4,5 30
1 x 150 (h) + 1 x 65 (h)
CSC051E
(CSC051E)
5 x GN 1/1 (70)
5 x 65 (h) 2 x 150 (h)
18 + 7,5 34
1 x 200 (h) + 1 x 150 (h)
CSC052E
(CSC052E)
5 x GN 2/1 (70)
5 x 65 (h) 2 x 150 (h)
36 + 15 50
1 x 200 (h) + 2 x 65 (h)
10 x GN 1/1 (70)
10 x 65 (h) 4 x 150 (h)
2 x 200 (h) + 4 x 65 (h)
CSD011E
(CSD011E)
1 x GN 1/1
150 (h)
6 + 2
37
CS
D012E
(CSD012E)
2 x GN 1/1 12 + 4
57
CSD013E
(CSD013E)
3 x GN 1/1 18 + 6
79
CSD0
0
1E
(CSD001E)
1 x GN 1/1 6 + 2
37
CSD0
0
2E
(CSD002E)
2 x GN 1/1 12 + 4
57
CSD0
0
3E
(CSD003E)
3 x GN 1/1 18 + 6
79
