Moen 7622SRS - Faucet Maintenance and Checks; Screen Cleaning and Re-installation

INS11736 - 8/21
1414
1616
1515
1717
1. Unscrew Pulldown Hose (J) from Spray Wand (G) and remove
screen and o-ring.
1. Renistall screen and o-ring as shown. Thread Pulldown Hose (J)
onto Spray Wand (G) and tighten.
1. Rinse debris from screen.
1. Re-check water flow.
11
2
1
2
1
G
J
J
G
J
1. Unscrew Pulldown Hose (J) from Spray Wand (G) and remove
screen and o-ring.
1. Unscrew Pulldown Hose (J) from Spray Wand (G) and remove
screen and o-ring.
1. Enjuaque los residuos del filtro.
1. Rincer le filtre pour en retirer tous le debris.
1. Renistall screen and o-ring as shown. Thread Pulldown Hose (J)
onto Spray Wand (G) and tighten.
1. Renistall screen and o-ring as shown. Thread Pulldown Hose (J)
onto Spray Wand (G) and tighten.
1. Vuelva a revisar el flujo de agua.
1. Vrifier de nouveau le ddit de ľeau.
