Moen Aromatherapy IN208C2 - Combination Shower Installation Instructions

6
Remove existing showerhead.
Use wrench if necessary.
Loosen Adjustable Nut (A2) to allow
Threaded Fitting (A1) to rotate.
1. Attach Rainshower (A) to Shower
Arm (F).
2. Rotate Threaded Fitting (A1) to Shower
Arm (F).
A1
A2
Combination Shower Installation
Instructions
2211
A
A1
F
1
2
33
Tighten Threaded Fitting (A1) with a
wrench.
A1
44
English
