MoJack 750XT - Hardware List; Hardware Identification; Tools Needed for Assembly; Required Tools

MoJack 750XT Lift
6
Hardware List
11
Item
No.
Qty. Description
Cap Screw M12-1.75 X 80
Cap Screw M12-1.75 X 65
Carriage Bolt M8-1.25 X 20
Nylock Nut – M12-1.75
Nylock Nut – M8-1.25
Push Pin
Clevis Pin
Small Hair Pin
Large Hair Pin
1
2
3
3
3
4
1
1
2
19
12
13
14
15
16
17
18
Tools Needed for Assembly
19mm Wrench (2) 13mm Wrench (1)
14
Nylock Nut – M12-1.75
15
Nylock Nut – M8-1.25
18
Small Hair Pin
19
Large Hair Pin
11
Cap Screw M12-1.75 X 80
13
Carriage Bolt M8-1.25 X 20
12
Cap Screw M12-1.75 X 65
16
Push Pin
17
Clevis Pin
