9
RIDING MOWER LIFT
OPERATING INSTRUCTIONS
STEP 3
Move Mower onto Mower Lift
The mower lift must be used on a solid level surface.
• Make sure the mower clears the 6” collapsed height of
the lift.
• Carefully roll or drive mower onto Wheel Pads.
• Place the mower in neutral or disengage hydraulic
drive.
• Stop engine and remove the key.
STEP 4
Strapping Front Mower Tires to Wheel Pads
Secure the front mower tires to the Wheel Pads
using the Safety Straps.
• Wrap the Safety Strap over the mower tire
and secure the hook into the loop on the
Wheel Pad .
• Tighten the Safety Straps by pressing down
on the metal clip.
4
Safety Strap
4
Wheel Pad
2
STEP 2
Aligning Wheel Pads to Fit Mower
• Place the mower lift wheel pads 6” in front of the
mower’s front tires.
• Remove Push Pins and align the Wheel Pads so
that the front tires will be centered on the Wheel
Pads.
• Replace the Push Pins to lock the Wheel Pads to
the Scissor Frame.
Wheel Pads must be equal distance from the
Scissor Frame to maintain proper balance.
4
2
