PERMANET INSTALLATION:
Remove the strings from the guitar.
Drill a ½’’ hole through the tailblock or
use a tapered reamer to enlarge the
existing hole.
CAUTION: This step should only
be performed by an experienced
professional!
Remove the strap button, small hex
nut, and small dress washer from the
smaller threaded portion of the endpin
jack to allow the larger threaded barrel
portion to pass through the hole from
the inside of the guitar.
Adjust the length of the larger threaded
barrel by moving the large hex nut
along with the dress washer and star
washer until the smaller portion of the
threaded barrel fully extends through
the tailblock. It should extend no more
than 11/32’’ (8.7mm) or a minimum of
5/16’’ (7.9mm) outside of the guitar.
1.
2
3.
