Please unfold page 3. Then you can always see the
operating elements and connections described.
1Operating Elements and Connections
1 Microphone with pop protection
2 VOLUME control
3 POWER LED
4 POWER switch
5 Talk button
button locked = microphone switched on
button unlocked = microphone switched off
6 Spring terminals for connecting a speaker (mini-
mum impedance 4 Ω)
7 Fuse holder; replace a burnt-out fuse by one of the
same type only
8 Mains cable
2 Safety Notes
This unit corresponds to all required directives of the
EU and is therefore marked with .
Please observe the following items in any case:
●
The unit is suitable for indoor use only. Protect it
against dripping water and splash water, high air
humidity, and heat (admissible ambient temperature
range 0 – 40 °C).
●
Do not place any vessel filled with liquid on the unit,
e. g. a drinking glass.
●
Do not operate the unit and immediately disconnect
the mains plug from the socket
1. in case of visible damage to the unit or to the
mains cable,
2. if a defect might have occurred after the unit was
dropped or suffered a similar accident,
3. if malfunctions occur.
In any case the unit must be repaired by skilled per-
sonnel.
●
Never pull the mains cable for disconnecting the
mains plug from the socket, always seize the plug.
●
A damaged mains cable must be replaced by the
manufacturer or skilled personnel only.
●
For cleaning only use a dry, soft cloth; never use
water or chemicals.
●
No guarantee claims for the unit and no liability for
any resulting personal damage or material damage
will be accepted if the unit is used for other purposes
than originally intended, if it is not correctly connect-
ed, operated, or not repaired in an expert way.
●
Important for U. K. Customers!
The wires in the mains lead of the unit are coloured in
accordance with the following code:
green/yellow = earth
blue = neutral
brown = live
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings identifying the terminals in your plug, pro-
ceed as follows:
1. The wire which is coloured green and yellow must
be connected to the terminal in the plug which is
marked with the letter E or by the earth symbol ,
or coloured green or green and yellow.
2. The wire which is coloured blue must be con-
nected to the terminal which is marked with the
letter N or coloured black.
3. The wire which is coloured brown must be con-
nected to the terminal which is marked with the
letter L or coloured red.
Warning
-
This appliance must be earthed.
3 Applications
The amplifier PAM-10 is specially designed for an-
nouncements. It supplies a power of 10 W and is
equipped with a gooseneck microphone and a talk but-
ton.
4 Connection
1) Connect a speaker (4 –16 Ω) to the two spring ter-
minals (6).
When connecting several speakers, make sure that
the total impedance will not fall below 4 Ω.
2) Connect the plug of the mains cable (8) to a mains
socket (230 V~/50 Hz).
If the unit is to be put out of operation
definitively, take it to a local recycling plant
for a disposal which is not harmful to the
environment.
WARNING The unit is supplied with hazardous
mains voltage (230 V~). Leave servic-
ing to skilled personnel only. Never
make any modification on the unit,
otherwise you will risk an electric shock.
GB
5
