GB
6
5 Operation
1) Switch on the unit with the POWER switch (4). The
POWER LED (3) will light up.
2) For making an announcement, press the talk button
(5) to lock it. When speaking into the microphone
(1), you should be as close to it as possible.
3) Adjust the desired volume with the VOLUME con-
trol (2). In case of howlback, reduce the volume
accordingly.
4) After the announcement, press the talk button once
again to unlock it.
6 Specifications
Output power at 4 Ω:. . . . . . 10 WRMS
Frequency range:. . . . . . . . . 80 –12 000 Hz
Speaker impedance: . . . . . . 4 –16 Ω
Type of microphone: . . . . . . electret, omnidirectional
Power supply: . . . . . . . . . . . 230 V~/50 Hz/12 VA
Ambient temperature: . . . . . 0 – 40 °C
Subject to technical modification.
All rights reserved by MONACOR
®
INTERNATIONAL GmbH & Co. KG. No part of this instruction manual may
be reproduced in any form or by any means for any commercial use.
