Monark 881 E - Page 15

Monark 881 E
15
Pos. Qty. Art. No. Description Pos. Qty. Art. No. Description
1 1 9145-2 Frame 28 2 9145-145 Crank axle
2 1 9030-6 Support tube, rear 29 1 9145-146 Crank bearing arm, right
3 2 9100-5 Plastic cap, blue 30 1 9145-147 Crank bearing arm, left
4 2 9010-12 Transport wheel, complete 31 2 9045-50 Arm extension fastener compl.
5 2 1066 Plastic cap, white 32 2 9145-49 Spring for above
6 1 9145-10 Cover with decals, complete 33 1 9145-60 Crank arm, left
5 21015-5 Mounting screw for cover 34 1 9145-63 Crank arm, right
7 1 9145-18 Rubber belt 35 2 9045-65 Collar
8 1 9145-20 Combination key 36 1 9145-66 Double keyed collar
9 1 9145-24 Flywheel 11 kg, complete 1 9145-72 Meter, complete
10 1 9045-27 Axle length 160 mm 26g 37 1 9371-68 -Digital meter
11 1 9010-38 Tension Pin 5x18 mm 38 1 9326-263 -Extension cable
12 2 9145-50 Washer 10x25x1.5 mm 39 1 9326-162 -Crank sensor with cable
13 2 9145-28 Bearing bushing 40 1 9145-69 -Holder for sensor
14 2 19001-6 Ball bearing 6001-2z 41 1 9371-67 -Holder for digital meter
15 1 9000-15 Lock ring SgH 28 1 9326-164 -Magnet
16 2 2420-49 Sprocket nut 42 1 9145-75 Plastic handle
17 2 1210 Sprocket 14t 43 1 9145-100 Transport handle
18 1 9145-30 Brake belt, complete 44 1 9145-101 Locking pin with chain
19 1 9145-32 Indicator 45 1 9300-205 Pedal (pair)
20 2 9145-92 Plate 1 9300-207 Foot straps (pair)
21 1 9145-33 Spring 46 1 9045-70 Handle, pair
22 1 9145-34 Bracket 47 1 9045-71 Handcover
23 1 9145-136 Tension lever, complete 48 1 9045-101 Wall bar fastener
24 1 9145-140 Handwheel with tension axle,
compl.
1 9145-550 Decal set for 881 E
25 1 6720 Crank bearing set, complete 1 9145-150 Set with screw, washer and nut
26 2 9007-36 Chain wheel, 34T 1 9145-8 Adjustable stand, accessory
27 2 9145-55 Chain 1/2 x 1/8”,42 l, incl. lock
