Monark 881 E
6
Operating Instruction
Workload adjustment
Monark Rehab Trainer model 881 E is an arm and
leg ergometer provided with a brake belt. The power
can be read in watts at 50 pedal rpm. The Rehab
Trainer is also equipped with an electronic meter
that shows pedal revolutions per minute (RPM),
total pedal revolutions (TOTAL COUNT) and time
(TIME) function.
Through cycling the test person supplies the flywheel
with a certain kinetic energy. This is braked by means
of a brake belt which runs around the bigger part of
the brake surface of the flywheel. The workload is
changed either by using another pedalling speed or
by increasing or decreasing the tension of the brake
belt against the flywheel by means of the work load
control knob.
Leg exercise in a lying position at the same level
as the ergometer.
Arm exercise in a sitting position
with the ergometer placed on a
table.
Leg exercise in a sitting position
with the ergometer placed on the
floor.
Arm exercise with the
ergometer hanging on the
wall bars.
Ergometer placed on a table for
wall bars.
Fig: Workload adjustment
1) Electronic meter
2) Graduated scale
3) Workload knob
