Mondraker Sly - Page 18

LOWER LINK KIT 36
SET 4
CHAIN GUIDE PLATE + BOLTS
CABLE GUIDE KIT
SET 5
SET 8
DETAIL 01 DETAIL 02
099.22101
099.24200
099.22300
099.25400
099.24018
099.25018
099.24072
099.25013
SET 1: ZERO BEARING KIT 26
SET 2: SHOCK HARDWARE KIT 18
SET 3: UPPER LINK KIT 30
SET 4: LOWER LINK KIT 36
SET 5: CHAIN GUIDE PLATE + BOLTS
SET 6: DISC ADAPTOR KIT
SET 7: BATTERY BOLTS SET
SET 8: CABLE GUIDE KIT
BEARING 3802-2RS, 24x15x7 (x8) / BEARING 6900V-2RS, 10x22x6 (x2)
SPACER, 10x17x6 (x2) / SHOCK BOLT (x2) / SHOCK BOLT (x1)
SPACER, 15x19x2.5T (x2) / UPPER LINK-RT SPACER (x2) / PIVOT AXLE, M12 (x2) / PIVOT AXLE, M15 (x2) / C-RING (x6)
SPACER, 15x27x2 (x2) / SPACER, 15x19x2.5t (x2) / INNER LOWER LINK SPACER (x1) / PIVOT AXLE, M10 (x1) / AXLE NUT,
M10 (x1) / MAIN AXLE (x1) / SPACER (x1) / TAPER NUT (x1) / SCREW BOLT (x1)
CHAIN GUIDE BASE (x1) / CHAIN GUIDE OUTER PLATE (x1) / SCREW BOLT, M5X12L (x2) / WASHER (x4) / SCREW BOLT,
M5x8-P (x1)
DISC ADAPTOR (x1) / SCREW BOLT (x2)
BATTERY SCREW BOLT (x2)
CABLE GUIDE (x1) / SCREW BOTL M2.5X5L (x1) / SCREW BOLT M3X10L (x1)
PART NUMBER DESCRIPTION COMPONENTS
SHOCK HARDWARE KIT 18
SET 2
ZERO BEARING KIT 26
SET 1
UPPER LINK KIT 30
SET 3
19
19
6
10
6
10
9
7
6
6
6
3
4
16
7
7
5
5
7
6
6
6
8
8
14
12
12
15
17
12
12
13
18
18
11
