Assembly 3
25
25
Figure 3.20
Front View of Bike
Cable barrel end
Single cable
casing
Cable
adjuster
Cable
splier
Upper cable
(short casing)
Upper plate
Bearing
Whenbrakeisengaged - minimum 1 mm (1/32”)
Football ends
Lower plate
Lower cable Lower cable
Locknut
Whenbrakeisdisengaged - minimum 1 mm (1/32”)
Keyed washer
Adjusng barrel
Locknut
Upper cable
(long casing)
Front brake
cable
Rear brake
lever
Front
brake lever
Cable adjusng
barrel
Brake cable slot
3
2
5
1 6
7
4
