Mongoose BMX - Page 47

Adjustments 4
45
45
Figure 4.20
Move the
handlebar le
or right unl it
is aligned with
the front wheel
Figure 4.21
Adjust the Handlebar Angle (all stem types)
❶ Using a 6 mm Allen wrench loosen the handlebar binder
bolt(s). Figure 4.21
❷ Rotate the handlebar into the desired posion.
❸ Check that the handlebar is centered to the frame and front
wheel. Sit on the seat and check your reach to grips, shiers
and brakes. Refer to Secon 1, Fig. 1.2: Seat Height and
Handlebar Reach for guidelines.
❹ Tighten the handlebar binder bolt(s) and check the
handlebar is securely aached and cannot move.
Align the Handlebar (with threadless stem)
❶ Stand in front of the handlebar and hold the front wheel
between your legs.
❷ Using a 6 mm Allen wrench, loosen the pinch binder bolts
and move the handle bar le or right unl it is aligned with
the front wheel. Figure 4.20
❸ Tighten the pinch binder bolts and check the handlebar is
securely aached and cannot move.
1
2
2
1
Pinch binder
bolts
