Centering brake
If you squeeze the brake and one side moves more than the other, or one side does not
move at all, then the brake is not centered, or the wheel is not centered. First determine
if the wheel is centered. Look at the gap between the re and the fork or frame on either
side. If it is not even, loosen wheel axle nuts and center the wheel, then proceed to
centering the brake. (Fig. 3.39, 3.40)
If the brake is not centered, look at the disc brake caliper for centering adjustment screws
at the center of the brake pad on either side. (Fig. 3.39) Looking down into the brake where
the brake pads contact the disc rotor, determine which side needs to move away or towards
the disc. Turn the centering adjustment screws so that there is about 1/32 of an inch of
clearance on either side of the disc rotor. Spin the front wheel and listen for any rubbing
noise or excess fricon. Repeat the steps unl the brake is centered.
Brake is correctly adjusted when:
• The brake pads do not drag on the rotor when the brake is open.
• Both brake pads move away from the rotor equally when the brake is released.
• When the brake is applied, the brake pads contact the rim before the brake
lever reaches about 1/3 of the way to the handlebar. (Fig. 3.41)
DISC GETS HOT! Severe injury could result from contact with the hot disc!
Mind your legs, as well as your hands.
These brakes require breaking in! Ride and use the brakes gently for 13 miles before
using the brakes in downhill condions, for sudden stops, or any other serious braking.
Please be aware that your brake system will change in performance throughout the
wear-in process. The disc brake should be cleaned before the rst ride using rubbing
alcohol. NEVER use oil or similar products to clean your disc brake system.
WARNING: Disc brakes are sharp, keep ngers away from brake caliper and
rotor. If ngers contact brake while wheel is turning injury can occur.
Aer adjusng brake, squeeze the brake lever as hard as you can several mes and re-
inspect the brake pads, centering, and brake lever travel. If the brake pads are no longer
square to the rim, repeat brake pad adjustments. Be sure that brake pads return to a
centered posion by spinning the wheel and listening for the brake pad rubbing the rotor on
either side. Readjust as needed. Check that the brake cable tension allows the brake lever
about 1/3 of the travel before the brake pads contact the rotor. If the cable has stretched or
slipped, readjust brake cable tension by loosening cable anchor bolt and pulling more cable
through the anchor or use brake adjustment barrels for ne tuning brake cable tension.
3.41
