Mongoose R6174 - Page 18

Assembly 3
17
17
Figure 3.7
Front View of Scooter
Single cable
casing
Cable
adjuster
Cable
splier
Upper cable
(short casing)
Upper plate
Bearing unit
Important! The gap between the plates and
bearing unit should be a minimum 1 mm (1/32”)
when the brake is engaged or disengaged.
Lower plate
Lower cable Lower cable
Locknut
Upper cable adjusng barrels
Locknut
Upper cable
(long casing)
Front brake
cable
Rear brake
lever
Front brake
lever
Cable adjusng
barrel
2
1
4
Lower cable adjusng barrels
3
4
1 mm
(1/32")
1 mm
(1/32")
