4 Adjustments
24
Figure 4.7
Figure 4.6
❷ If the gap between the brake pad and wheel is uneven,
adjust the posion of the brake pad. Figure 4.6
• Loosen the nut on the back of the brake.
• Squeeze the brake and hold the brake lever closed, while
re-ghtening the lock nut on the back of the brake.
Note: Watch the brake, if it begins to shi or rotate, then
release the brake lever, and use your hand to rotate the
brake caliper back unl both sides of the brake move
equally. Somemes it is necessary to over-rotate the brake
slightly, so that as you ghten the locknut, the brake will
end up centered.
❸ Pull and release the brake lever a few mes and check if the
pads are centered.
❹ If necessary, repeat steps one and two unl the brake pads
are centered and the gap between the pads and rim is close
to 1/8 inch. Figure 4.7
Distance from
brake pad to
wheel rim is
1/8 inch
Axle nut
Brake pad
Wheel rim
Tire
Brake pad
lock nut
Locknut on
brake pad
