Quick Start Guide Eco Connect Plus Convection Ovens | 4/5/7/10-Tray | Steam
FG0BX-UK-QSG-0300 | Rev. B23 (July 2023) MONO 35
Glass-door cleaning
The door consists of two parts:
An outer fixed glass panel
An inner glass panel which can be opened for ease of cleaning.
1. Remove the screws shown in Figure 5, which allows the inner glass panel to be opened (Figure 6).
2. Clean the door glass with a soft damp cloth. For more stubborn stains, use a proprietary glass cleaner.
− Do not use scouring agents or anything abrasive, as they can scratch and damage the glass.
3. Re-secure the inner glass with the screws when finished cleaning.
Figure 5: Location of the two screws for releasing the inner glass
A. Undo the two screws to release the inner glass for cleaning
Figure 6: Inner glass panel moved away from the door
