Mono Ecotouch - Diagnostics

FG245 Ecotouch RIGID DECK Rev A17 11-04-17
44
9 - 8 DIAGNOSTICS
SETTINGS SCREEN
TOUCH “DIAGNOSTICS” AND THE FOLLOWING SCREEN WILL APPEAR.
TOUCH THE REQUIRED OUTPUT AND A SIGNAL IS SENT TO THAT ITEM.
THE OUTPUT BEING CHECKED IS HIGHLIGHTED WHEN ACTIVE.
TO STOP THE OUTPUT, PRESS AGAIN.
INPUTS HIGHLIGHT WHEN A
SIGNAL IS Received.
e.g. DOOR OPEN
DIAGNOSTICS SCREEN
