Installation and Operation Manual MONO Bx Eco-connect Ovens
FG0BX-UK-MAN-0200 | Rev. A21 (July 2021) MONO 61
PART 1 / SECTION 3
10 TRAY - COOLING FAN AND DAMPER
DAMPER SOLENOID L/H OVEN B749-83-003
DAMPER SOLENOID R/H OVEN B749-83-004
PART 17
REAR FAN UNIT
B869-75-018
PART 34
REAR FAN UNIT FUSE
B842-85-025
PART 35
AUX. POWER OUTLET FUSE
B842-85-039
PART 37
PART NUMBERS REFER TO DRAWING M1500E25-75100 IN ELECTRICAL MANUAL
DAMPER BRACKET 150-02-01000
COUPLING
158-02-00600
FG150
