Monogram 30 inch - Features of Your Oven

49-85247 15
Design
information
NOTE: Not all
features are on
all models.
Features of Your Oven
Professional Dual Fuel Range
2
3
1
4
Full Extension Oven Rack Broiler Pan and Grid
Temperature Probe Roasting Rack
14
8
5
13
11
12
9
10
7
6
Feature Index Page
1 Full Extension Oven Rack(s)
— 2 in large oven
— 2 in small oven
18, 19, 23, 30
2 Broiler Pan and Grid 22, 29
3 Temperature Probe 24, 31
4 Roasting Rack 22, 29
5 Automatic Oven Door Latch 26
6 Broil Elements (2) 29
7 Halogen Oven Lights 32
8 Oven Rack Supports
— 5 positions in large oven
— 4 positions in small oven
19, 23
9 %DNH(OHPHQWVXQGHURYHQÀRRU 29
10 Oven Door Seal 33
11 Oven Frame Seal 33
12 Temperature Probe Outlet
— right side in large oven
— left side in small oven
24
13 Convection Fan 22, 23
14 Oven Door 31, 33
NOTE: On models equipped with 2 ovens, both ovens have same features.
