STEP 4 Remote Trigger Connections
1. Connect one end of the 1/8”-to-1/8” mono mini cable to the remote output of your receiver/preamp
(or MPA 3250). Should your receiver not have a remote trigger out, the 12V power transformer can be
plugged into the switched AC outlet on the back of your receiver.
2. Connect the other end of the 1/8”-to-1/8” mono mini cable to the remote trigger in of the MPA 2250.
If you are using the 12V power transformer, connect the end with the 1/8” mono mini jack to the
remote trigger in of the MPA 2250.
3. Connect one end of the 1/8”-to-1/8” mono mini cable to the remote output of the MPA 2250 and
the other end to the component you wish to control.
From MPA 3250 Receiver/Preamp
Remote Trigger
Out
To
Extra Amp or Accessory
Trigger In
