SPECIFICATIONS
MPA 2250 SPECIFICATIONS
Number of Channels 2 Channels Bridgeable
Power Output - Stereo 250w @ 8Ω from 20Hz – 20kHz all channels driven
400w @ 4Ω from 20Hz – 20kHz all channels driven
Power Output – Bridged Mono 650w @ 8Ω from 20Hz – 20kHz all channels driven
THD + Noise <0.01% at 1 KHz and <0.02% at 20 KHz, at rated power 8 Ohms
Frequency Response 20 Hz – 20 KHz +/- 0.1 Db
Signal to Noise >110 dB from A-weighted below rated power
Crosstalk >70db at 20KHz
Slew Rate 70v/microsecond
Damping Factor 600
Input Impedance 50k Unbalanced / 25k Balanced
Input Sensitivity 1.55v for 250W; 1v for 100W
Gain 29db
Bandwidth 300kHz @ 1W - 8Ω Load
Remote Trigger In 3 – 30v AC/DC 15mA +/- 5mA
Remote Trigger Out 12V DC 100mA
Dimensions Width Without Rack Ears : 17in / 434mm
Width With Rack Ears: 19in / 484mm
Height With Feet: 7.75in / 193.5mm
Height Without Feet: 7in / 177mm
Depth: 20.25in / 514mm
Weight Net Weight: 75lbs / 34kg
Shipping Weight: 88lbs / 40kg
