MPA 2250 OPERATION
MPA 2250 FRONT PANEL
1. Channel Output Power Meters – These meters show the current power output in watts
for the Left and Right Channels respectively. The center display shows the Total Power Output
for both channels.
2. Power Indicator – Illuminates blue when amplifier is powered ON.
3. Left Channel Full Power Indicator – When this LED is lit, the left channel is at full power.
When this LED is ON, volume of receiver/preamp should be decreased.
4. Power Button – Turns amplifier On/Off. If a 12V trigger is being used, this button should
not be needed once the amplifier is installed.
5. Meter Dimmer Control – Increases or decreases the brightness of the Power Output Meters.
Meters will brighten through 12 steps and then turn off.
6. Right Channel Full Power Indicator – When this LED is lit, the right channel is at full power.
When this LED is ON, volume of receiver/preamp should be decreased.
MPA 2250
Signature
MONSTER HOME THEATRE MUSIC
TWO CHANNEL REFERENCE POWER AMPLIFIER
WATTS
RIGHT CHANNEL
WATTS
LEFT CHANNEL
WATTS TOTAL
POWER
ON/OFF
DISPLAY
BRIGHTNESS
LEFT CHANNEL
FULL POWER
POWER
ON
RIGHT CHANNEL
FULL POWER
1
2 43 5 6
