DES-192
REV 1.0
3
Measurement Guide
12”
38”
17”
40”
Port Side
Center of Header
CAUTION: All measurements are extremely critical. Any deviation may cause damage to the canvas top or boat.
Use these measurements as a guide for installation on both sides of the tower.
Use a center punch to create a
divot for each screw to start in.
Use a 9/64” drill bit to start
a pilot hole for each screw.
OR
During this install we started with the port side first then went to the starboard side.
Additional Tips:
!
To Next Page
