STANDARD -760K SERIES INSTALLATION DIMENSIONS
(Consult factory for specific model dimensions)
Moog Inc., East Aurora, NY 14052-0018
Telephone: 716/652-2000
Fax: 716/687-7910
Toll Free: 1-800-272-MOOG
www.moog.com
TJW/PDF RevD, January 2023, Id. CDS7155
NOTES
TYPICAL WIRING SCHEMATIC
The products described herein are subject to change at any time without notice, including, but not limited to, product features, specifications, and designs.
1 Valve Weight:
1.1 lbs (0.5 kg)
2 Polarity:
A&C (+), B&D (-) produces flow out
port B
3 Manifold O-Rings
0.070 (1.78) sect x 0.426 (10.82) I.D.
(Universal dash No. 13)
0.070 (1.78) sect x 0.364 (9.25) I.D.
(Universal dash No. 12) for optional
X-port
4 Surface:
Surface to which valve is
mounted requires
32
( ) finish, flat
within .001 [0.025] TIR
5 Electrical Connector:
Mates with MS3106-14S-2S or equivalent;
others on request
6 Null Adjust:
Flow out of port B will increase with
clockwise rotations of null adjust pin
7 Compressed Oil Volume
for one control port: 0.229 in3
(3.75 cm
3
)
8 Suggested Mounting Screws:
0.312-18 x 1.750 lg (M8 x 45)
socket head screw (4 req’d)
Dimensions in parenthesis are in millimeters.
2
A B C D
Figure 4
DD
TANK PORT T
PRESSURE PORT P
CONTROL PORT B
3.88
1.94
1.750
.875
.670
.875
.437
CONTROL PORT A
1.500
.500
3.000
1.750
.390
3.500
VALVE MOUNTS ON THIS
MANIFOLD SURFACE
.437
.875
.670
1.281
2.562
1
PORT PER SAE J1926
1.0625-12 UN-2B DASH 12
STR THD O-RING BOSS
(.75 [19.05] TUBE OD REF)
4 PLACES
1.00
4 PL
1.25
63
2.00
2.11
4.22
RET
AUX PRESS
760
PORT PER SAE J1926
.4375-20 UNF-2B DASH 4
STR THD O-RING BOSS
(.25 TUBE OD REF)
.001
.156 (3.96) AUXILIARY
PILOT PRESSURE PORT
.008
M
4X .312 [7.92]
.014
M
4X .3125-18 UNC-2B THD
.007
M
.015
M
.136 .20
.014
M
.50 .63
4X .344 [8.74] THRU
[50.8]
[53.6]
[107.19]
[31.75]
[44.45]
[22.23]
[50.8]
[17.02]
[11.1]
[38.1]
[76.2]
[12.7]
[9.91]
[44.45]
[88.9]
[98.55]
[49.28]
[65.07]
[32.54]
[49.28]
[11.1]
[17.02]
[25.4]
CERTIFICATION CONTROLLED RELATED DOCUMENT
THIS INSTALLATION INSTRUCTION IS CERTIFICATION CONTROLLED.
REVISION SHALL BE APPROVED BY THE MOOG ICD Ex/ATEX
AUTHORIZED PERSON AND MAY REQUIRE APPROVAL BY THE ATEX
NOTIFIED BODY.
APPLICABLE CERTIFICATE(S):
KEMA 02ATEX1015 X
KEMA 02ATEX1016 X
