Moomba Outback User Manual

73
© 2011 Skier’s Choice, Inc.
The hull identification number is located on the upper right
hand side of the transom below the rub rail.
IDenTIfICaTIon nUMbeR
Hydrogen and oxygen gases are produced during normal
battery operation or charging. Sparks or flames can cause
this mixture to ignite and explode if it comes near the vent
openings. Sulfuric acid in the battery can cause serious
burns if spilled on skin or in eyes. Flush with clear water
immediately!
baTTeRY sPeCIfICaTIons
Section XIII
Technical Information
A good Quality Marine Dual Purpose Battery is
recommended.
Fuel Delivery
Horsepower:
Displacement:
Bore (in):
Stroke (in):
Compression Ratio:
Electrical System:
Ignition Type:
Alternator Output:
Thermostat:
Firing Order:
Initial Timing:
Oil Filter:
Oil Capacity:
Oil Type:
Spark Plugs:
Gap (in):
RPM Range @ WOT:
Fuel Type:
Engine Model:
Model:
Ratio:
Oil Type:
Oil Capacity:
V-Drive:
RV-26 D
1.46 to 1
SAE - 30
2 Pints
Walters
2011 Moomba Engine & Transmission Data
Multi-Port Fuel Injection
325 HP
350 CI
4.00
3.48
9.4 to 1
12-V Negative Ground
Electronic Distributor
70 Amps @ 1,200 RPM
162 Degrees F
1-8-4-3-6-5-7-2
Non-Adjustable
Pennzoil PZ - 52
5.5 - Quarts
Pennzoil 15W - 40 Marine
AC 41 - 101
0.040
4,400 - 4,800 RPM
89 Octane - Unleaded
Indmar Assault MPI 325
Multi-Port Fuel Injection
340 HP
350 CI
4.00
3.48
9.4 to 1
12-V Negative Ground
Electronic Distributor
90 Amps @ 1,200 RPM
162 Degrees F
1-8-4-3-6-5-7-2
Non-Adjustable
Pennzoil PZ - 52
5.5 - Quarts
Pennzoil 15W - 40 Marine
AC 41 - 101
0.040
4,600 - 5,200 RPM
89 Octane - Unleaded
Indmar Assault MPI 340
Multi-Port Fuel Injection
409 HP
364 CI
4.00
3.62
9.6 to 1 (Premium Fuel Required)
12-V Negative Ground
Electronic Distributorless Coil Near Plug
90 Amps @ 1,200 RPM
162 Degrees F
1-8-7-2-6-5-4-3
Non-Adjustable
Pennzoil PZ - 167
6 - Quarts
Pennzoil 15W - 40 Marine
AC 41 - 110
0.040
5,200 - 5,600 RPM
92 Octane - Unleaded
Indmar Assault MPI 409
Model:
Ratio:
Oil Type:
Oil Capacity:
Transmission:
450 D
1 to 1
ATF Dextron III
2 Quarts
ZF Hurth
