MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Page
Date
23
MAR 2017
Rev Date
24- 50- 00 - ELECTRICAL LOAD DISTRIBUTION
24- 51- 00 - POWER DISTRIBUTION SYSTEM
The power Buss distributes direct current power to the
electrical system from the alternator and from the se-
lected battery through the battery relay. The batteries
negative leads attach to a structural ground on the air-
frame. The Master Switch “ON” closes the relay and
supplies power to the aircraft electrical system.
-CAUTION-
Do not reset a circuit breaker after it has tripped
a second time. If necessary to do so to locate
the malfunction, be alert for a possible electrical
fire. Breakers are “Trip Free” type and cannot be
held in the closed position.
24-50-00
