MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Date
MAR 2017
Rev Date
Page
7
timeter consists of four parts; Altitude Window,
Altitude Tape, Barometric Setting Window and
optional Altitude Trend Bar.
AIRSPEED Indicator portion of t he display
will always appear on the bottom display. The Air-
speed Indicator Display consists of three parts;
Airspeed Window, Airspeed Tape and Airspeed
Limitations or Range Markings.
4. GARMIN GDU 10(XX) PRIMARY FLIGHT DIS -
PLAY (PFD)
See description in “Garmin G1000” earlier in this
section.
5. GARMIN GDU 10(XX) MULTI- FUNCTION
FLIGHT DISPLAY (MFD)
See description in “Garmin G1000” earlier in this
section.
6. GARMIN GMA 1347 AUDIO PANEL
See description in “Garmin G1000” earlier in this
section.
7. MAGNETO/STARTER SWITCH
Magneto/Starter switch combines both ignition
and starting functions. Turning ignition key clock-
wise through R, L, and BOTH to START position
and then pushing forward on key and receptacle,
engages starter. Releasing key when engine
starts allows switch to return, by spring action, to
BOTH position.
8. ALTERNATOR FIELD SWITCH
This switch cuts alternator field power from main
buss to alternator.
9. MASTER POWER SWITCH
Master switch operates battery relay which con-
trols battery power (selected battery) to main
buss. T his switch cuts ALL ship power OFF, ex-
cept cabin overhead lights and baggage
compartment light.
10. BATTERY SELECT SWITCH - BAT 1/BAT 2
This switch allows pilot to select either battery as
primary for any flight. Battery #1 is normally used
for operations. The battery not being used is re-
charged through a trickle charge system. It is rec-
ommended to switch batteries occasionally.
11. EMERGENCY BUS SWITCH (Optional when
Stand- by Alternator is installed)
When Low Voltage annunciator light illuminates,
steady or flashing, pull 90A BAT circuit breaker
and PUSH EMERG BUS switch ON to bring
Stand- by Alternator online.
12. STROBE LIGHT SWITCH
Strobe light switch turns wing tip and tail strobe
lights ON.
13. NAVIGATION LIGHT (NAV LITE) SWITCH
Navigation light switch turns wing tip and tail navi-
gation lights ON.
14. TAXI LIGHT (TAXI LITE) SWITCHES (L & R)
15. LANDING LIGHT (LDG LITE) SWITCHES (L
&R)
Select and push split switches to turn desired set
of lights ON. Push switches OFF to turn desired
set o f lights off. Lights should be operated only for
short time periods while not in flight to preclude
overheating of lamps. Overload protection is
achieved by circuit breakers in panel.
16. GEAR SAFETY BY PASS SWITCH (Gear Re-
traction Override)
Gear safety override switch is a manual means of
electrically by-passing the Air speed Safety
Switch. In the event the landing gear switch is
placed in gear-up position, a properly operating
Airspeed Safety Switch prevents gear from being
retracted before take off speed of approximately
60 5 KTS is reached. To retract landing gear at a
lower air speed, the GR SAFETY BY PASS
switch may be held de-pressed until landing gear
is completely retracted.
-CAUTION-
Activation of landing gear safety override
switch overrides the safety features of air-
speed safety switch and CAN cause landing
gear to start retracting while aircraft is on
ground.
17. LANDING GEAR SWITCH
Electric gear switch, identified by its wheel
shaped knob, is a two-position switch. Pulling aft
and lowering knob lowers landing gear while pull-
ing aft and raising knob raises landing gear.
-NOTE-
Failure to “Pull” knob out prior to move-
ment may result in a broken s witch.
18. GEAR DOWN POSITION INDICATOR
The gear- down position indicator, located on
floorboard near back of fuel selector valve pan,
aft of center console, has two marks that align
when landing gear is down and illuminates when
GREEN GEAR DOWN light is ON. A red-white
striped decal shows when landing gear is NOT in
thedownposition.
39-10-00
