MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Page
Date
14
MAR 2017
Rev Date
REAR SPAR (REF)
PICK UP (30) B/P FASTENERS EACH SIDE OF SPLICE CENTERLINE
PICK UP (15) B/P FASTENERS EACH SIDE OF SPLICE & - 503 ANGLE
RIVETS (REF)
AN 470- AD6
B
A
B
A
2024- T3 CLAD (.050)
-503 PLATE
(18) AN 470- AD5 RIVETS
EACH SIDE OF SPLICE
-503 (REF)
W.S. 43.5
20.0
COND. ”N” STEEL)
- 503 FLAT PATTERN (.040 AISI 4130,
COND. ”N” STEEL)
- 501 FLAT PATTERN (.091 AISI C 130,
28.0
1.56
.74
1.07
1.66
SECT A- A
THRU SKIN AND - 503
(10) AN 470- AD4 RIVETS
CAPS AND - 501 ANGLES
TO ADS THRU SPAR
STEP UP AN426- AD4
THIS AREA.
210055 CAP (REF)
DETAIL A
W.S. 21.75
A
L
STUB SPAR (REF)
SECT B- B
AIRPLANE
C
82
-505 PLATE(REF)
98
- 501 (REF)
WEB (REF)
210054- 7
- 507
STUB SPAR REPAIR
FIGURE 51- 13
51-13-03
