Mooney M20V - Page 75

MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Page
Date
6
MAR 2017
Rev Date
JACK POINT
TIE DOWN
RING
WARNING
DO NOT USE AS
A JACK POINT
ADJUSTABLE JACKSTANDS
ENGINE
LIFT POINT
“A” FRAME
WITH CHAIN HOIST
(LYCOMING ENGINE)
WARNING
DO NOT USE PROPELLER JACKS
OR PROPELLER STANDS
ENGINE
LIFT POINTS
(CONTINENTAL ENGINE)
DO NOT LEAVE ON
AIRCRAFT DURING FLIGHT
JACK AND LIFT POINT LOCATION
FIGURE 7- 1
7-10-00
