Moore Industries RIY - Page 18

RIY
16 The Interface Solution Experts
Figure 7. RIY, HP-style Outline Dimension (FL Housing shown)
Figure 8. RIY, DIN-style Outline Dimensions
82.5 m m
(3.25 in)
72.6 m m
(2.86 in)
61 mm
(2.40 in)
SAVE
CANCEL
ZER O SPAN
67 mm
(2.63 in)
63 mm
(2.46 in)
75.4 m m
(2.97 in)
37.8 m m
(1.50 in)
+PS 4321-PS
CANCEL
SAVE
35 mm
(1.38 in)
80 mm
(3.15 in)
ZERO SPAN
128.5
mm
(5.06 in)
4321 +PS –PS
