2.1 Injection pipe installation
The injection pipe connects to the injection valve of dishwasher and the corner valve of
pipe or tap. The injection pipe is supplied with the dishwasher. Attention: Please use the
supplied new injection pipe to connect with tap and valve. The old and damaged pipe
may cause water leakage.
Attention: When injecting water from the tap, please put the plastic stopper on the suction
port to avoid water leakage.
Tap
(Back diagram)
Injection pipe
Injection pipe
Injection valve
Plastic stopper
Injection pipe
connects with
the valve
Convenient port
Tap seal ring
Tap connector
Convenient port adapter
