74.Routethebackupcamerawireharness(2)thoughthe
liftgatewireharnessgrommet(3)withtheliftgatehar
ness(1)tothepointofconnectingtothebackupcam
eraconnectorfromthenewlightbar.Attachtotheve
hiclewiringharness(1)withtiestrapswhereneces
sary.
75.Backouttheconnectorterminallockingtabfromthe
backupcameraconnector.
76.Insertthebackupcameraharnesswiresintobackup
cameraconnectorasfollows:
a.12Vignitionpowerwire(PK/OR)cavity2
b.Signalreturnwire(GY/OR)cavity3
c.Signalwire(GY/LB)cavity4
d.Shieldwire(Bare)cavity7
e.Groundwire(BK)cavity5
77.Preparethelightbar(1)forinstallationbytapingthe
licenselampconnector(3)tothebackupcamerahar
ness(2).
Feb02,2011K6861161
