K6862043
3/11/14
5
16. Install the actuator rods (2) to the latch control using
the reference marks made during the removal
procedure.
17. Install the tailgate cover and liner (if equipped).
NOTE: If the vehicle is equipped with the tailgate lock
actuator, you must remove and transfer the two
wires from the existing b
ody side tailgate
connector to the supplied body harness (A)
connector. See graphic for more information.
18. If equipped with the tailgate lock actuator, remove the
wires (1, 2) from the existing tailgate connector (3),
then discard the existing tailgate connector.
19. Remove the terminal plugs from cavities 7 and 8 in
the supplied body harness connector (A).
20. Transfer the P237 DG/TN wire removed from cavity
7 of the original connector and transfer into cavity 7
of the supplied harness connector.
21. Transfer the P235 LG/TN wire removed from cavity 8
of the original connector and transfer into cavity 8 of
the supplied harness connector.
