Install Sensor on Tank
6. The sensor mounts to the bottom center of the tank using the collar set.
7. When choosing the location on the bottom of the water tank, the sensor should be at least 2 inches away
from any side wall.
8. The collar set has pre-applied 2-sided adhesive. The tank must be properly prepared, or the collar will
not adhere.
9. The tank must be thoroughly cleaned with soap and water in the area of the sensor install.
10. Allow the water to dry, then clean the area with an alcohol pad or similar, to remove all grease.
11. Lay the collar set in the center of the tank bottom, and mark as needed to guide the final prep and
installation of the collar onto the tank.
12. In the area marked, where the adhesive will contact the tank, thoroughly apply the primer supplied with
the collar.
13. Separate the collar pieces, peel the backing paper from the base piece, and stick to the tank per your
markings. Thoroughly press the ring all the way around. Pressure is required to force the tape to adhere
to the tank.
14. Apply a generous amount of the supplied sonic grease directly to the rubber pad before attaching sensor
to the tank.
15. Install sensor inside the collar, rubber pad against tank.
16. Now snap the retaining ring onto the collar set.
