19
MINIMUM OUTPUT ADJUSTMENT
Before starting any adjustments disconnect the
appliance from the mains power supply. Adjustments
must be carried out with the tap at the "SAVING"
position.
The minimum gas output is correctly adjusted when the
inner cone of the flame arrives at the height of 3 to
4mm.
If this is not the case, first remove the tap knob and
then tighten or loosen the screw C, depending on
whether the flame is to be reduced or increased.
The adjustments must be crried out so that the end
position of the tap is actually its minimum position.
For butane/propane the screw C must be fully screwed
in.
-
ғ
,
3
4 ғ
,
„ ",
,
ғ
-
ғ
,
3- 4 - ,
ғ
,
« » ,
,
ғ
PRIMARY AIR ADJUSTMENT
To access the primary air adjusting screw (5), open or
remove oven door and remove oven bottom (2). By
unscrewing the adjusting screw the quantity of primary
air is increase, by tightening it is reduced. The air/gas
mixture is correct when the flame has blue color.
Adjust screw 5 for value X in accordance with the table,
and tighten the nut.
Check that the burner is working properly: the flame
must be blue and sharp, without a yellow tip.
ғ
(
)
ғ
, - ғ
( „“)
ғ
, :
ғ
ғ
( ,
),
ғ
,
– ғ
(„“ )
ғ
:
ғ
1 – Front oven wall
2 – Oven bottom
3 – Ignition tube
4 – Oven burner
5 – Oven burner adjusting screw
1 –
2 –
3 –
4 –
5 –
1 –
2 –
3 –
4 –
5 –
