Voltage dips,
short interrup-
tions and voltage
variations on
power supply
input lines
IEC61000-4-11
<5 % UT (>95
% dip in UT)
for 0,5 cycle
40 % UT (60
% dip in UT)
for 5 cycles
70 % UT (30
% dip in UT)
for 25 cycles
<5 % UT (>95
% dip in UT)
for 5 sec
<5 % UT (>95
% dip in UT)
for 0,5 cycle
40 % UT (60
% dip in UT)
for 5 cycles
70 % UT (30
% dip in UT)
for 25 cycles
<5 % UT (>95
% dip in UT)
for 5 sec
Mains power quality should
be that of atypical commer-
cial or hospital environment.
If the user of this device
requires continued operation
during power mains inter-
ruptions, it is recommended
that the device be powered
from an uninterruptible
power supply or a battery.
Power frequency
(50/60Hz)
magnetic field
IEC61000-4-8
3 A/m
3 A/m
Power frequency magnetic
fields should be at levels
characteristic of atypical
location in a typical commercial
or hospital environment.
NOTE UT is the a.c. mains voltage prior to the application of the test level
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity -
Thie Excel devices are intended for use in the electromagnetic environment specified below. The
user of this device should make sure it is used in such an environment.
Immunity Test IEC60601
test level
Compliance Electromagnetic
Environment-Guidance
Conducted RF
IEC 61000-4-6
3Vrms150
kHz to 80
MHz outside
ISM bandsa
3 Vrms
Portable and mobile RF communi-
cations equipment should be used
no closer to any part of this device,
including cables, than there com-
mended separation distance calcu-
lated from the equation applicable
to the frequency of the transmitter.
Recommended separation
distance
d = 1.2√ P 150 kHz to 80 MHz
d = 1.2√ P 150 kHz to 80 MHz
d = 2.3√ P 80 MHz to 2.5G MHz
Where P is the maximum output po-
wer rating of the transmitter in watts
(W) according to the transmitter ma-
nufacturer and d is the recommended
separation distance in meters (m).b
Field strengths from fixed RF
transmitters, as determined by
an electromagnetic site survey c,
should be less than the compliance
level in each frequency ranged.
Interference may occur in the
vicinity of equipment marked
with the following symbol:
Radiated RF
IEC 61000-4-3
3 V/m 80
MHz to
2.5 GHz
3 V/m
