Morgan MEDesign BASIC-ONE CSA-UL - Page 17

Schematic AC 120 V Model
BASIC-ONE – (UL- CSA)
90001-03
AC INPUT
AC INPUT 120 VAC, 60 HZ
12 11 10 9 8 7 6 5 4 3 2 1
TERMINAL STRIP S1
DUAL CIRCUIT
BREAKER 16A
ON LID COVER, BASE
POWER CABLE TO “MAGNETICS” “KOM” SERIES POWER CONTROLLER
LEGEND-
W = WHITE WIRES - NEUTRAL - COMMON
B = BLACK WIRES – HOT – ACTIVE PHASE
G = GREEN AND GROUND WIRES
BLOCK DIAGRAM
CHASSIS
CONNECTION
G B
W
W
B
HOLE IN LID
OF BASE
HOLE IN LID OF BASE
B
W
G
WITHIN BASE
LIFT MOTOR
TREND MOTOR
R/L TILT MOTOR
AC CONTROL 1 2 3
KOM CONTROLLER
B
IN
OUT
OUT
IN
TYPES OF KOM CONTROL UNITS
KOM 14-020A-000 5 PORT, 3 PORTS USED
KOM 33-020A-000 3 PORT, ALL PORTS USED
EMERGENCY STOP
SWITCH
LINE
FILTER
CORCOM 50-60 HZ
15EHT1
B
B
G
W
W
ALARM
TROUBLE
POWER
AUDIO
ALARM
RENTEC
STATUS
MONITOR
POW+
POW-
TROB+
TROB-
ALRM+
ALRM-
BP+
BP-
V+
NH-OK
NL-OK
NS1-OK
NS2-OK
OV
LINE
NEUT
SENS1
SENS2
0V +12V
12 POWER SUPPLY- 2 AMP
UL LISTED CSA, CE
1
2
3
4
5
6
3
4
5
6
7
8
1
2
3
4
5
6
8
10
2 1
VERSION
FOR 120V
V+5
NH-OK
NL-OK
NS1-OK
NS2-OK
OV
UL LISTED
MID400
TERMINAL STRIP
FOR WIRE ATTACH
ONLY, WIRE
COLORS ARE COLOR
OF INDICATOR
RED
BLACK
W
W
B
B
HOLE
B
W
ITEMS IN YELLOW ON SEPARATE STRIP
ON
FRONT
PANEL
MAINS, LINE IN, 3 WIRE,
PROTECTIVE GROUND
HOSPITAL GRADE
ON FRONT PANEL
MONITOR ASSEMBLY IS MMI-20048-01
