A-18 DAILY INSPECTION
Type C
1) Place the main power switch in the [OFF] position.
2) While pushing the shutter plates in the direction of arrows, attach a padlock.
Type D
1) Place the main power switch in the [OFF] position.
2) Put a driver into the release screw.
When the release screw is not prepared, just pull out the lock plate.
3) While turning the driver CCW, pull out the lock plate.
4) Attach a padlock.
Shutter plate
NOTE
Driver
Lock plate
To Next Page
