REGULAR INSPECTION B-39
15.2 Adjusting Air Pressure
After the installation of the machine, adjust the main air pressure.
The main air pressure can be adjusted with the regulator mounted at the air control unit panel.
The shape of the regulator may differ depending on the machine model.
<Procedure>
(Example)
1) Supply the compressed air.
2) Pull down the pressure adjusting knob in the
regulator.
3) Turn the pressure adjusting knob to set the main air
pressure.
For the setting pressure, refer to the MACHINE
SPECIFICATIONS in the MAINTENANCE
INFORMATION published separately.
CW rotation: Pressure increases
CCW rotation: Pressure decreases
4) After adjusting the pressure, push the knob.
NOTE
Pressure
adjusting
knob
Pressure gage
To Next Page
