Moro PM 80A User Manual

Rev. 00 of 01.01.2009 12 / 29
 Refit the rear cover with the lubrication pump (together with the coupling inside
the rotor shaft) on the endplate.
3.5.2 Reassembly of the drive side section
AM Version
 Replace all gaskets and oil seals.
 Fasten the gearbox endplate to the pump body by means of the specific screws.
 Make sure bearing is fully seated in endplate.
 Insert the key on the shaft and fit the pinion gear on the rotor shaft.
 Fasten the self-locking nut positioning the pinion gear.
 Install the gear with taper shaft.
 Position the gearbox cover gasket.
 Refit the gearbox cover using the previously removed screws.
AP Version
 Replace all gaskets and oil seals.
 Fasten the drive side endplate to the pump body by means of the specific screws.
 Make sure bearing is fully seated in endplate.
 Refit the drive side cover with the specific screws.
 Insert the key on the rotor shaft.
 Refit idle pulley to rotor shaft.
AD Version
 Replace all gaskets and oil seals.
 Fasten the drive side endplate to the pump body by means of the specific screws.
 Make sure bearing is fully seated in endplate.
 Refit the drive side cover with the specific screws.
 Insert the key on the rotor shaft.
 Refit coupling to rotor shaft.
AH Version
 Replace all gaskets and oil seals.
 Fasten the drive side endplate to the pump body by means of the specific screws.
 Make sure bearing is fully seated in endplate.
 Insert the key on the rotor shaft.
 Fit the hydraulic motor support and coupling set.
 Refit the hydraulic motor with the specific screws.
