Pull the water tank buckle to
the horizontal state.
1
Guidance on feeding water and disassemble & washing of the
water tank
INSTRUCTIONS
Unscrew the rotary knob in "—" shape
manually (90° anticlockwise) to separate
the water tank from the water pump
module (including the water pipe).
3
Water pump module
Rotary knob in "—" shape
7
Position of clean water pump shown
(It is recommended to clean every 3 months
to extend the service life.)
5
After feeding water or cleaning the water
tank, install the water pump module in the
water tank. Insert front hook into the slot
of the water tank, and then rotate rotary
knob in "—" shape clockwise for 90°, and
close it as shown in the figure.
6
2 Pull out the water tank completely,
place it on a stable place, add water
and push the water tank into the fuselage.
4 Pull out the tank completely to clean
and add water.
