morse 15 - Parts List and Diagram

Parts List and Diagram
for Morse Can Tipper Model 15
Manufactured 05/2006 to _______
MODEL 15
CAN TIPPER
The Specialist In Drum Handling Equipment
Website: www.MORSEmfgco.com
COPYRIGHT 2006 MORSE MFG. CO., INC. Form PL 15 (0506) (Updated 10/2006) Page 3
ITEM QTY PART # DESCRIPTION
1 1 1687-P CAN HOLDER ASM, 15
2 1 4283-P CATCH ASM, 15 W/ SCREW
3 2 4234-P CAP, PLASTIC, HANDLE, CATCH 15
4 1 1686-P SCREW, THUMB, 5/16-18 X 3/4
5 6 1518-P NUT, LOCK, 1/4-20 NYLON
6 6 1517-P SCREW, PANHEAD, 1/4-20 X 5/8
7 1 4277-P BASE ASM, 15 SERIES
8 1 4281-P CENTER BRACE, 15
