4
Stove typeStove type
Stove typeStove type
Stove type
Back of stove (A) Sides of stove (B) Distance to Furniture Back of stove (A) Sides of stove (B) Distance to Furniture
Back of stove (A) Sides of stove (B) Distance to Furniture Back of stove (A) Sides of stove (B) Distance to Furniture
Back of stove (A) Sides of stove (B) Distance to Furniture
Morsø 2110 150 mm 500 mm 850 mm
Morsø 2130 150 mm 500 mm 850 mm
Morsø 2140 150 mm 200 mm 800 mm
Morsø 3410 350 mm 600 mm 800 mm
Morsø 3440 350 mm 300 mm 800 mm
Morsø 3450 350 mm 600 mm 800 mm
Morsø 3610 350 mm 600 mm 800 mm
Morsø 4600 150 mm 250 mm 800 mm
Morsø 4640 150 mm 250 mm 800 mm
Morsø 5010 350 mm 600 mm 800 mm
In brick-recess situations we recommend that the stove be fitted with a gap all
around of between 10-15 cm to allow for heat circulation purposes. It also makes
for easier maintenance of the external parts.
Hearth RequirementsHearth Requirements
Hearth RequirementsHearth Requirements
Hearth Requirements
Please refer to Building Regulations regarding thickness and area of the hearth
required.
Clearances to FurnitureClearances to Furniture
Clearances to FurnitureClearances to Furniture
Clearances to Furniture
The clearance to any furniture should be minimum of 80 cm, however, it is also
necessary to assess whether the furniture or anything else close by will be effected
by the warmth i.e. dried out.
The distance to any combustible material in front of the stove is minimum 60cm.
1.5 The chimney1.5 The chimney
1.5 The chimney1.5 The chimney
1.5 The chimney
The stove must never be connected to a chimney that is shared with another appli-
ance. A modern and efficient stove makes a lot of demands on a chimney. Ask the
chimney sweep to assess the chimney.
The chimney’s internal diameter must be minimum 175 cm² (150 mm in diameter)
and preferably not larger. A chimney with an excessively large area may struggle to
establish a good draught. If the chimney is of a masonry construction with a larger
internal diameter it is recommended that a chimney liner be fitted. In this way the
flue is reduced and an increased draught is achieved increasing fuel efficiency.
1.6 Stovepipe connection1.6 Stovepipe connection
1.6 Stovepipe connection1.6 Stovepipe connection
1.6 Stovepipe connection
The standard stove is fitted with a reversible flue collar (3). If a rear flue outlet is
required simply fit the supplied cast iron blanking plate onto the top outlet, fitting
the flue collar onto the back. For a top flue outlet, simply reverse the procedure.
