Morso 6143 B - Page 9

Table 7 – Dilution Tunnel Gas Measurements and Sampling Data Summary
Run
Length of Test
(hh:mm;ss)
Average Dilution Tunnel Gas Measurements
Velocity
(ft/sec)
Temperature
(°F)
1
1:17:50
21.59
91
2
2:30:50
21.59
91
4
02:26:10
21.29
88
Model Similarities
All versions of the 6100 B series share the same firebox, flue, and combustion air system. Model
differences are limited to variations of the pedestal base.
Model 6140 B was the tested model, it sets on a short pedestal base that is approximately the same
diameter as the stove body.
Model 6143 B has a taller pedestal similar in diameter as the 6140 B that is offered with and without a
wood storage compartment.
Model 6148 B has a pedestal that is similar in height to the 6143 B but has a reduced diameter between
the base and the firebox.
Model 6170 B has no pedestal, it is designed as a wall hanging appliance.
Photos of these variations are in Appendix 26 of DTI report number 300-ELAB-2381-EPA.
9 of 37
